American LandMaster Part # 16935 : TUNE UP KIT FOR KOHLER CH640/ECH650
Category: Parts Dept/American LandMaster/Tune-up Kits
For more parts ordering information? See [Parts Info] Tab above^
The American LandMaster Tune-up Kit for 400/450 series Utility Vehicles with a 390cc Honda Engine
Contains everything you need to keep your UTV engine running year after year, this Tune-up kit keeps your utility vehicle in tip top shape by performing our recommended maintenance as outlined in your units owners manual.
This KIT Includes:
- 1 Subaru air filter element
- 2 qt. (32 oz.) of 10W-40 motor oil. Note: 52 ounces is required for an oil change
- 1 Oil filter
- 2 Spark plugs
- 1 Fuel Treatment - Ethanol/Stabilizer
- 80W-90 gear oil. Note: 7 ounces needed for the 90 degree gear box.
- 1 qt. (32 oz.) SAE30 for transaxle. Note: 20 ounces needed for the transaxle.
- 1 8oz. bottle of Hilliard front diff oil. Note: 5 ounces is required
Maintenance Schedule:
- Oil should be changed after the first 5 hours of use and every 100 hours thereafter.
- Foam pre-cleaner should be cleaned weekly and replaced annually or every 200 hours.
- Air cleaner element should be cleaned and/or replaced annually or every 200 hours.
- Spark plug should be replaced annually or every 100 hours.
- Gear oil for the transaxle should be changed every 200 hours.
- Gear oil for the 90 degree gear box should be changed every 600 hours.
- Front diff oil should be changed every 200 hours.
- Fuel treatment - ethanol/stabilizer should be used every time you add fuel.
WARRANTY INFORMATION
• 3 years: Engine Warranty by LCT.
• 90 days: Frame, Brush Bars, Spindles, Seat Frame.
• 30 days: All other components.
See operator’s manual for detailed warranty information. Color, graphics and/or specifications subject to change without notice. Vehicles not for race/rental track use.
IMPORTANT!
Please DO NOT pick parts by description or pictures!. Utilize your Parts Manual (only) to determine your correct part(s). A “Blueprint” image will be in your parts manual along with your parts relative location. Once you retrieve the part# (usually 4+ digits), you simply type-in that part# into our sites Search Box (located in the top upper right side of all site pages). If you need a Parts Manual?, please request a free copy of your Parts Manual here.
PART NUMBERS "2-" PREFIX?
These are UTV Parts only!. (ie) Part# 2-12345 has no relation to normal part# 12345. The Prefix simply indicates that it's usage is solely for UTV (Utility Vehicles) by Brister and ASW. Do NOT mix-in any "2-" part#'s into your order (if you are ordering normal non "2-" prefix ordered parts). Thank you!
