TUNE-UP KIT, 150CC
Category: Parts Dept/American LandMaster/Fluids
For more parts ordering information? See [Parts Info] Tab above^
The American LandMaster Tune-up Kit for: 200 series Light Utility Vehicles that have an oil filter
Kit Includes:
- 1 Oil filter
- 1 Air filter
- 1 qt. (32 oz.) of 10W40 motor oil. Note: Only 30 ounces is required for an oil change
- 1 Fuel filter • 1 Spark plug (Set gap to be .024 - .027)
- 1 qt. (32 oz.) of 80W-90 Gear oil. Note: Only .8 quart is needed.
- 1 13 oz. Chain Lube • 1 Fuel Treatment - Ethanol/Stabilizer
Maintenance Schedule:
- Oil should be changed after the first 5 hours of use and every 20 hours after.
- Air filter should be inspected and cleaned monthly and/or replaced every 20 hours. Should be replaced at a minimum of once a year.
- Fuel filter should be inspected monthly and replaced annually.
- Spark plug should be cleaned quarterly and replaced as needed.
- Chain should be lubricated every 90 days.
- Gear oil should be changed annually.
- Fuel treatment - ethanol/stabilizer should be used every time you add fuel.
WARRANTY INFORMATION
• 3 years: Engine Warranty by LCT.
• 90 days: Frame, Brush Bars, Spindles, Seat Frame.
• 30 days: All other components.
See operator’s manual for detailed warranty information. Color, graphics and/or specifications subject to change without notice. Vehicles not for race/rental track use.
IMPORTANT!
Please DO NOT pick parts by description or pictures!. Utilize your Parts Manual (only) to determine your correct part(s). A “Blueprint” image will be in your parts manual along with your parts relative location. Once you retrieve the part# (usually 4+ digits), you simply type-in that part# into our sites Search Box (located in the top upper right side of all site pages). If you need a Parts Manual?, please request a free copy of your Parts Manual here.
PART NUMBERS "2-" PREFIX?
These are UTV Parts only!. (ie) Part# 2-12345 has no relation to normal part# 12345. The Prefix simply indicates that it's usage is solely for UTV (Utility Vehicles) by Brister and ASW. Do NOT mix-in any "2-" part#'s into your order (if you are ordering normal non "2-" prefix ordered parts). Thank you!
